Crystal Clear Transparent Epoxy Curing Agent for Electronic Encapsulation

Brand Name:	DAHUA
Model Number:	DH-1618S
MOQ:	2000
Price:	4.55-5.35
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Amine Value (mg KOH/g):

270 ± 20

Density At 25 °C:

Active Hydrogen Equivalent Weight (AHEW):

Appearance:

Colorless, Transparent, Clear Liquid

Viscosity At 25 °C (mPa·s):

200-600

Glass Transition Temperature (Tg):

68 °C

Highlight:

Electronic Encapsulation Curing Agent

Crystal Clear Epoxy Hardener

Transparent Coating Curing Agent

Product Description

Product Category

Modified Cycloaliphatic Amine Curing Agent

Product Applications

This curing agent is recommended for use with standard bisphenol-A epoxy resin (EEW 190) and low-viscosity epoxy resin. When combined with DH-1618S, the system is ideal for transparent casting applications, including ornaments and decorative products, glass coatings, transparent electronic encapsulation coatings, and solvent-free topcoats.

Product Performance

Excellent weather resistance, moisture resistance, and mechanical properties

Low color, low odor, and complete curing at low temperatures

High hardness and flexible curing conditions

Improved physical properties after heat curing

Product Data

Typical Properties

AppearanceColorless, transparent, clear liquidGardner Color≤ 2Amine Value (mg KOH/g)270 ± 20Viscosity at 25 °C (mPa·s)200-600Active Hydrogen Equivalent Weight (AHEW)97Mixing Ratio with Reference Resin (EEW 190)100 : 50Density at 25 °C0.99Glass Transition Temperature (Tg)68 °CGel Time, 100 g, with Reference Resin30-50 minHardness of 100 g cured mass (Shore D)80-852 mm thin film - Tack-free Time2-2.5 h2 mm thin film - Full Cure Time16-24 h0.2 mm coating film - Room Temperature12 h0.2 mm coating film - Heated at 120 °C25-30

Notes

All above test data were obtained under laboratory conditions at 25 °C.

Keep the product tightly sealed in its original container. Crystallization may occur when stored below 0 °C. If crystallization occurs, heat the product to 25 °C until it becomes clear again.

The typical values shown above are obtained from standardized laboratory tests and represent the general performance of the product. They are provided for the buyer's reference only and should not be regarded as final specifications.
